The REASON is redefining the e-bike category with a high-performance frame that´s both lightweight and engineered with unbeatable kinematics. It absorbs vibrations without sacrificing responsiveness and delivers agility, control and precision at all times. Its sleek, integrated design looks just like a muscular bike - no one would guess it's electric, not even up close.
Modify the head tube and rear triangle angles to suit your riding style or terrain type.
One frame, four possible configurations.
Maximum versatility for riders who want it all.
· DJI Avinox M1 Motor -120Nm 1000W (Boost mode) / 105Nm 1000W
· Integrated 800 Wh LI-ION battery
· Reason Full Carbon frame, Boost, 140 mm wheel travel
· Fox 36 SL Factory Kashima fork with 140 mm travel
· Fox Float Factory Kashima shock
· Sram XX AXS T-Type 12-speed drivetrain
· Shimano XTR 4-piston hydraulic disc brakes
Specification:
Frame: Reason Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 140 mm
Fork: Fox 36 Float SL Factory, 140mm Travel, Grip X, HSC, LSC, HSR, LSR, Kabolt SL Axle x 110, 1.5 Tapered, 68HT, 44mm Offset
Shock: FOX Float Factory Kashima, 210x47,5 mm, Evol LV, Low Speed Rebound, 2 Position
Headset: Acros AZX-589 ZS56 blocklock 150º
Motor: DJI Avinox M1, 120Nm 1000W (Boost mode) / 105Nm 1000W, 5 assistance modes, 150rpm
Battery: DJI Avinox 800 Wh, 35,9V, IP56
Display: DJI Avinox DP100, touch screen OLED full colour 2-Inch, 800nits, 326ppi
Rear Derailleur: SRAM XX Eagle AXS T-Type 12s
Shifters: SRAM XX AXS controller
Crankset: 34T BCD 104mm with chainring bolt / Forged AL6061/T6 165mm beat blasted anodized black
Cassette: SRAM XX Eagle T-type 10-52T
Brakes: Shimano XTR BR-M9920, hydraulic disc 4-Piston, 203/203mm
Tires: Front: Pirelli Scorpion 29x2.4 MTB scM Trail ProWALL SmartGRIP / Rear: Pirelli Scorpion 29x2.4 MTB scR Trail ProWALL SmartGRIP
Hubs: DT Swiss HXC 1200 Carbon e-bike SP 29 CL 30
Wheels: DT Swiss HXC 1200 Carbon e-bike SP 29 CL 30
Handlebar: Full Integrated Carbon Handlebar / S, M size 60 x 760 mm / L, XL size 80 x 760 mm
Seatpost: Fox Transfer Kashima SL 31,6mm telescopic seat post, remote adjustment S size 100 mm Drop / M, L size 125 mm Drop / L size 150 mm Drop
Seat: Fizik Ridon X1
